CHAUVET DJ – DMX-4 Dimmer Relay Pack | Four-Channel DMX-512 Controller for Non-DMX Fixtures | Variable Electronic Dimming, Independent Addressing, Built-In Chase Patterns | LED Lighting Control

It's a 4-channel dimmer/relay pack providing DMX control for on/off or dimming to units not equipped with DMX on their own. The fixture is optimized for use with small LED fixtures to prevent ghosting and flickering. Each of the 4 sets of outlets (duplex) can be set to any DMX address and independently set as a dimmer or relay. Sixteen user-selectable chase patterns make programming a breeze. 4-channel dimmer/switch pack optimized for use with small LED fixtures Each channel can be set to any DMX address which makes it extremely easy to program Each channel can be individually set as a dimmer or a switch which offers great flexibility 4 duplex outlets allow up to 8 devices to be controlled simultaneously Separate LED indicators clearly show the status of each channel Easy-access to built-in automated programs generate a synchronized show Automated programs have adjustable speeds and dimmer levels which offer great control without DMX DMX channels: 1, 2 or 4 Power output: 5A per channel, 15A max Input voltage equals output voltage AC power: Autoswitching 100-240VAC 50/60Hz Weight: 5lbs (2.2kg) Size: 8.3 x 7.7 x 2.8in (210 x 194 x 70mm)

• FOUR-CHANNEL DMX-512 DIMMER AND RELAY PACK: DMX-4 provides DMX-512 control for fixtures not equipped with DMX capability. Supports both on/off switching and dimming control. Designed to integrate non-DMX units into DMX-based lighting systems.
• INDEPENDENT CHANNEL CONFIGURATION AND ADDRESSING: Each channel can be set as either a dimmer or a relay. Every channel may be assigned to any DMX address independently. Allows flexible routing and control of mixed fixture types.
• VARIABLE ELECTRONIC DIMMING CONTROL: Features adjustable electronic dimming from 0 to 100 percent. Supports adjustable speed control and dimming with or without DMX input. Provides manual operation when DMX control is not available.
• OPTIMIZED FOR SMALL LED FIXTURES: Engineered to reduce ghosting and flickering when controlling small LED lights. Ensures stable and consistent output performance. Ideal for LED-focused lighting applications.
• BUILT-IN CHASE PATTERNS WITH WARRANTY SUPPORT: Includes sixteen user-selectable chase patterns for simplified programming. Helps speed up setup for events and installations. Backed by a 1-year limited warranty.
