Geloo Fuel Sending Unit with Fuel Gauge Kits 16" (400mm) Boat 316 Stainless Steel Fuel Level Sensor Fuel Water Tank Sender Gas Tank Sending Unit Boat Gauge for Boat Truck RV 240-33ohm
$90.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by v1.seanmas.com.au
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
$90.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by v1.seanmas.com.au
Free 30-day returns Details
Product details
| Management number | 214022582 | Release Date | 2026/04/12 | List Price | $36.00 | Model Number | 214022582 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- STANDARD OUTPUT: Fuel Level Sender and Fuel Gauge are suitable for American standard output 240-33 ohms (240 ohms empty, 33 ohms full). A variety of sizes to meet the cars, boats, yachts, RVs, agricultural vehicles and industrial equipment and other different sizes of fuel tanks
- NOTE: The output signal of the sensor is 240-33 ohms, so the fuel gauge must be adjusted to: 3/4 (240-33 ohms) to match. Please refer to Figure 2 for more information. Easy to install and connect. Fuel Sending Unit and fuel gauge with various backlight colours are equipped with gaskets, mounting screws and instructions
- FUEL SENSOR: Fuel Tank Sending Unit is made of 316 stainless steel, SAE 5 hole mounting pattern, NBR material gasket and controlled by high-quality reed switches. It can be corrosion resistance, no rust, stable output signal, long service life, accurate measurement, suitable for Marine applications
- FUEL GAUGE: With IP67 waterproof and dustproof grade, 316 Stainless Steel Bezel for long-term use even in acid-base and humid environment. Input signal Adjustable:0-190ohm, 240-33ohm, 240-30ohm, 0-180ohm, 10-180ohm; Install diameter: Φ52mm or 2-1/16''; Indication range: E~F; Working voltage: 9-32v dc [ fit 12V-24V Vehicle or Engine]
- MULTI-COLOUR: Fuel tank gauge with 7 Color Backlight Adjustment : red-yellow-orange-green-blue-purple-white, you can choose which one you want color that press the gauge back button. Connection: Red:+9-32VDC; Black: Signal Input; Orange: Backlight(+); Blue--Ground(-)
| Brand Name | Geloo |
|---|---|
| Unit Count | 1.0 Count |
| Item Weight | 0.93 Pounds |
| Manufacturer | Geloo |
| Material Type | Stainless Steel |
| Item Dimensions | 13.98 x 11.18 x 3.2 inches |
