Sealed Aviation Connector MX23 5 Pin Whole Set Glass Sealed Male Plug and Female Socket Docking Type Glass Sealing

plugsProduct Features Product name: MX series airtight connector Contact: Copper gold-plated Connection method: threaded connection Wiring method: Welding Socket material: glass sintered Environmental temperature: -55 ° C~+125 ° C Air tightness: ≤ 1x10-4 Pa. cm 3/s Insulation resistance: ≥ 1000MQ Rated voltage: 200v Voltage withstand: 1000V

• plugs
• MX23 Sealed Aviation Connector，5 Pin，Male and Female， Plug and Socket Straight
• MX series airtight circular connector socket male pin made of Kovar alloy gold-plated with good physical properties. The insulation materials are all made of UL certified PA66 nylon material which has excellent wear resistance self-lubricating properties high mechanical strength and is safer and more convenient.
• The connection method of this series of connectors is threaded locking connection which is convenient to use.
• The socket adopts glass sintering process with good airtightness.
• Widely used for circuit connection between electronic devices and power supplies in various electronic instruments and sealed containers. Prevent gas leakage The leakage rate can be ≤ 1X104Pa Cm3/s; The temperature it can withstand can reach 125 degrees
